Sandwich Panel Line
DongHae MMC’s high-efficiency sandwich panel line is engineered for continuous production of premium insulated wall and roof panels using EPS, PU, PIR, mineral wool, or hybrid core materials.
This Korean-manufactured sandwich panel line delivers outstanding insulation performance, structural durability, and fast production speed with advanced mixing head technology and precision control.
Ideal for cold storage facilities, warehouses, logistics centers, and industrial buildings, DongHae MMC’s export-quality line offers strong cost-efficiency and top-tier panel quality trusted by global manufacturers.
Contact DongHae MMC for detailed specifications and customized solutions.
Key equipment layout for Sandwich Panel Line
General Specification
[ Panel ]
Thickness
Length
Width
Surface pattern
Side pattern
[ Insulation ]
Material
Density
Metering type
Dispense
Foam pressure
Standard - 50, 75, 100T(Possible 40 ~ 150mmT)
Min. 1,500mmL (Cutting tolerance ±5 mm/10 m)
Standard 1,000mmW
Trapezoidal, Rib, Groove
Concealed, Overlapped joint
Polyurethane , Isocyanate
Approx. 40 kg/㎥
High-pressure metering
Cross traversing mix head
Max. 0.4 ㎏/㎠
